Εμφανίστε στην οθόνη σας 4 διαφορετικά περιεχόμενα σε ανάλυση 1080p ή 720p με το πάτημα ενός κουμπιού . Διαμορφώστε εσείς την εμφάνιση του διαμοιρασμού σε 4 διαφορετικές διατάξεις . Με εισόδους εικόνας Hdmi το Screen content Splitter μπορεί να δεχτεί όλες τις πηγές που μεταδίδουν εικόνα και ήχο σε αυτήν την μορφή . Ιδανικό για πρακτορεια ΟΠΑΠ , αφού μπορεί να προβάλει 4 διαφορετικά περιεχόμενα σε μια τηλεόραση . Συνεργάζεται και με ψηφιακά Modulators

This HDMI 4x1 switch is a Seamless switch with Multiview features with high performance. It supports four HDMI input sources which can be displayed on one screen with five Multiview modes: it integrates video signals from 4 different video sources for viewing on a single monitor. For the four connected inputs, it also functions as a switch with fast switching between seamless sources. It can be controlled by various ways, through the front panel button, IR, RS232 control, etc.

Features
• HDMI 4x1 Multi-viewer with seamless switcher
• Accepts up to 4 HD sources and it is capable of scaling and dimensioning the images and send them to a single Full HD display for Multiple view
• Compliant with HDMI 1.3a and HDCP 1.2
• Supports High Definition resolution up to Full HD 1080p
• Supports 4 in 1 Quad Multi-viewer and seamless switch (with same resolution)
• Quick switch between the HDMI sources (Seamless)
• Supports scaler up and scaler down function
• Supports button, IR control, RS232 control
• Supports multi output resolution
• Material: metal
• Color: black

Technical specifications
• Maximum Single Link Range: 1920x1080@60
• HDMI input/Output connector: Tipo A 19 pin
• Vertical Frequency Range: 50/60Hz
• Video amplifier Bandwidth: 2.25Gbps
• Input resolution: 480i60Hz, 480p60Hz, 576i50Hz, 576i60Hz, 720p50/60Hz, 1080i50/60Hz, 1080p24/25/30/50/60Hz
• Output resolution: 720p, 1080p

Application
• Video switch
• Surveillance for multi camera
• Car quad monitor
• Video format converter
• Multimedia panel

Dimensions
• Width: 148.5 mm
• Deep: 103 mm
• Height: 21.5 mm
• Weight: 342 g

Environmental specifications
• Operating temperature: 0°C to +70°C
• Operating humidity: 10% to 85%RH (no condensation)
• Storage temperature: -10°C to 80°C
• Storage humidity: 5% to 90%RH (no condensation)

Power
• External power supply: 12V DC@2A
• Power consumption: 10W

Package contents
• HDMI 4x1 Multi-viewer with seamless switcher
• Power supply 5V / 2A
• User’s manual
• Remote control
