• Video Compression: Smart H.265+; H.265; Smart H.264+; H.264
• Video Input Channels: 8 Ch
• PoE Interface: 8 Ch
• HDD Interface: 1
• RAID: No
• RCA Audio in/out: 1/1
• Incoming Bandwidth: 160 Mbps
• Network Interface: RJ-45 10M/100M/1000M
• Power Supply: 53 VDC, 1.81 A
• Dimensions: 260.0 mm x 232.5 mm x 47.6 mm(10.24" x 9.15" x 1.87")
• Weight: 0.92 kg
• Power Consumption: Total output of NVR is <10 W(without HDD) Total output power of PoE is 72 W,the maximum output power of asingle port is 25.5 W
• Working Temperature: –10 °C to +55 °C (14 °F to +131 °F)
• Max. Image Resolution: 3840 x 2160
• Decoding Capability: AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fp
• Full Channel Recording Resolution on MP Analysis: 1080p@30fps
• Τεχνιτή Νοημοσύνη: AI Dahua
• Alarm In/Out: No
• Built-in SSD: No
• HDMI/VGA: 1/1
• Hard Disk: 1 SATA port. Each disk can contain up to 20 TB
