• CVBS Output: 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 x 576, NTSC: 704 x 480
• Video Input Channels: 16 Ch
• RCA Audio in/out: 1/1
• Incoming Bandwidth: 160 Mbps
• Power Supply: 100 to 240 VAC, 50 to 60 Hz
• Dimensions: 445 x 400 x75 mm ( 17.5"x 15.7" x 3.0")
• Weight: < 5.6 kg (12.3 lb)
• Power Consumption: <80W
• Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
• Video Compression: H.265+/H.265/H.264+/H.264
• HDD Interface: 4
• RAID: No
• Full Channel Recording Resolution on MP Analysis: 1080p@30fps
• Network Interface: 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
• Alarm In/Out: 16/4
• HDMI/VGA: 2/1
• Max. Image Resolution: 3840 x 2160
• Encoding-Recording Resolution: 32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/2CIF/CIF/QCIF
• Τεχνιτή Νοημοσύνη: Acusense
• Hard Disk: Up to 4 SATA interfaces for HDD connection
