Features Description   Product Name 4G LTE Router   Ports Netoekt Port 2*LAN  1*WAN   SIM Card Standard SIM Card   Button Reset   DC Input: 12V-1A   Chipset Platform MTK   Basic Information Chipset model MT7620N   WiFi Standard IEEE 80 2.11 /b/g/n   DDR/SPI 64MBytes/8MBytes   RF WiFi Frequency 2400MHz-2483.5MHz   Antennas 3dbi X 2   WIFI Max. Power 802.11b   24dBm±2dBm;802.11g   16dBm±2dBm;802.11n   15dBm±2dBm;   Software Languange English   APN Setting Support   Systems Setting Support   WIFI Setting Support   Netowrk Setting Support   Firewall Setting Support   LED Support   Technical Standard WiFi Standard 802.11b/g/n(2*2 11n features)   Encrytion WPA/WPA2   Support Systems Windows XP   Windows Vista   Windows 7/8/10   MAC   Linux   Environment Working Temperature -10 to 50 degree centigrade   Storeage Temperature -40 to 70 degree centigrade   Humidity 5% to 95%   4G Information       Features Description   Chipset Platform Marvell   Basic Information Chipset model Marvell Chipset   Speed CAT4   SIM Card Standard 6PIN Port3V or 1.8V   BAND GSM Band 3/8   TDS Band 34/39   WCDMA Band B1/B3/B5/B7/B8/B20   LTE TDD Band 38   LTE FDD Band 1/3/5/8   Antennas 2 × 2 DL SU-MIMO for LTE and HSPA   Max. Power LTE: +23dBm TD -SCDMA 2GHz ：+24dBm                                                            WCDMA: +24dBm GSM 900MHz: +33dBmGSM 1800MHz/1900MHz: +30dBm EDGE 900MHz: +27dBm EDGE 1800MHz/1900MHz: +26dBm   Technical Standard GSM/EDGE/TD-SCDMA/LTE Speed EDGE： DL 236.8kbpsTD-HSPA： UL 2.2Mbps；DL 2.8Mbps                                       WCDMA: HSPA+: DL 21 Mbps UL 5.76 MbpsTD LTE ： UL 50Mbps；DL 150MbpsFDD LTE ：UL 50Mbps；DL150Mbps   3GPP Version FDD-LTE/ TD-LTE 3GPP Release 9TD-HSPA ：3GPP Release 7EDGE/GPRS/GSM ：3GPP Release 4   Environment Working Temperature -30～+75 degree centigrade   Storeage Temperature -40 to 85 degree centigrade   Humidity 5% to 95%
